Chapter 4 : TECHNICAL SPECIFICATIONS
4-1. COMPUTER INPUT(ON HD 15 OR BNC CONNECTORS)
Software compatibility:
Hardware compatibility:
Levels:
Impedance:
4-2. RGB / YUV / HDTV INPUT
Accepts signals from both Computer & Video Sources (RGsB, RGBS, YUV, HDTV Compatible Sync & Rate).
Line Frequency:
Frame Frequency:
Bandwidth:
• RGsB & RGBS INPUT
Line Frequency:
Levels:
Impedance:
• YUV INPUT
15.625 kHz / 50 Hz (625 L) ..... 15.735 kHz / 60 Hz (525 L).
Levels:
Impedance:
• HDTV INPUT
Levels:
Impedance:
4-3. S.VIDEO (Y/C)
15.625 kHz / 50 Hz (625 L) ..... 15.735 kHz / 60 Hz (525 L).
Levels:
Impedance:
All software compatible.
PC, MAC , WORKSTATION.
Resolution : From VGA (640 x 480) to UXGA (1600 x 1280).
RGsB, RGBS, RGBHV compatible.
Line Frequency : From 31.5 kHz to 150 kHz.
Frame Rate : From 24 Hz to 170 Hz.
RGB Bandwidth : 300 MHz.
R, G, B = 0.7 Vp/p.
H & V Sync. = TTL.
COMP Sync. = 0.3 Vp/p or TTL.
SOG = 0.3 Vp/p.
75 Ohms (R, G, B) ; Hi-Z (H & V and COMP Sync.).
from 15 kHz to 150 kHz.
from 24 Hz to 170 Hz.
300 MHz.
(ON 3 OR 4 BNC CONNECTORS).
from 15.625 kHz to 150 kHz.
R, G, B = 0.7 Vp/p.
COMP SYNC = 0.3 Vp/p or TTL.
SOG = 0.3 Vp/p.
R, G, B = 75 Ohms.
(ON 3 BNC CONNECTORS).
Y = 0.7 Vp/p (Luma) + 0.3 Vp/p (Sync.).
U, V = 0.7 Vp/p.
75 Ohms.
(ON 3 BNC CONNECTORS)
Y = 0.7 Vp/p with ± 0.3 V Tri-level Sync.
Dr = 0.7 Vp/p (with Tri-level Sync.).
Db = 0.7 Vp/p (with Tri-level Sync.).
RGB = 0.7 Vp/p with ± 0.3 V Tri-level Sync.
75 Ohms.
(ON 4 PIN MINI DIN OR 2 BNC FEMALE CONNECTORS)
Y = 1 Vp/p (0.7 Vp/p Luma + 0.3 Vp/p Sync.).
C = 0.3 Vp/p (Chroma Burst).
75 Ohms (Chroma & Luma).
