Chapter 1 : INTRODUCTION
Chapter 1 : INTRODUCTION
1-1. SUPPLIED EQUIPMENT
• 1 SMART BOOSTER
• 1 AC Power Supply Cord.
• 1 VGA M / M HD 15 Cable (1.8 m / 6 ft).
• 1 S.VIDEO (Y / C) Cable (1.8 m / 6 ft).
• 1 RCA / RCA (M / M) Cable (1.2 m / 4 ft).
• 1 RCA F / BNC M adapter.
• 1 Set of 19" brackets.
• 1 User's manual.
1-2. GENERAL INFORMATION
The SMART BOOSTER
RGB/S, RGsB, YUV, Computer, Video & HDTV signals.
Each of the 4 Inputs can be split into 3 separately buffered and amplified Outputs. It is the equivalent of integrating in
the same enclosure, 4 different Distribution Amplifiers of 1 to 3 Outputs each.
The SMART BOOSTER
Workstation, Line Doubler, Scaler, Video Presenter, Video & Industrial Camera, VCR, DVD, Laser Disc ....
PAGE 4
SMART BOOSTER
™
(SMB413).
™
is a Multi-Way 4 x {1 Input to a 3 way Output} Distribution Amplifier for RGB HV,
™
splits and boosts any Computer, HDTV and TV sources such as PC, MAC , Laptop, any
™
SMART BOOSTER™
