Basic Board Plasma CTV
Pos.Nr. Bestell-Bezeichnung
°
Item N
.
BUCHSEN/FASSUNGEN
11
Kurzschluss-Stecker .............................. Plug ............................................... 321-16821
TRANSISTOREN
10
SILPOW TO220FP PNP 80V 3A 24W .. Transistor ...................................... 346-28633
Q 02
BC847B SOT23 .................................... Transistor ...................................... 344-14974
Q334
STD2N52 IPAK .................................... Transistor ...................................... 346-27894
Q338
STH15NA50-FI ISOWATT 218 .............. Transistor ...................................... 346-27868.Y18
Q504
STY34NB50 .......................................... Transistor ...................................... 346-27857
Q508
STY34NB50 .......................................... Transistor ...................................... 346-27857
Q527
BC638-16 .............................................. Transistor ...................................... 346-20622.020
Q596
POWMOS TO220FP NCH 50V 10A 30W .... Transistor ...................................... 346-18528
Q624
POWMOS TO220 NCH 600V 8A ......... Transistor ...................................... 346-22395
Q663
POWMOS TO220FP NCH 50V 10A 30W .... Transistor ...................................... 346-18528
Q681
BC557B ................................................. Transistor ...................................... 346-74878.020
Q682
SILPOW TO220FP PNP 80V 3A 24W .. Transistor ...................................... 346-28633.Y22
DIODEN
10
STTB812FI TO220 STM ...................... Diode ............................................. 352-27867.Y21
D203
BB 640 SOD323 ................................... Diode ............................................. 351-26568
D204
BB 535 SOD323 ................................... Diode ............................................. 351-26570
D222
BB 640 SOD323 ................................... Diode ............................................. 351-26568
D241
BB 640 SOD323 ................................... Diode ............................................. 351-26568
DIODEN
D242
BB 535 SOD323 ................................... Diode ............................................. 351-26570
D303
BB 639 SOD323 ................................... Diode ............................................. 351-26571
D304
BB 535 SOD323 ................................... Diode ............................................. 351-26570
D314
Gleichrichter FBI5L1M1 900V/5A ......... Rectifier ......................................... 354-27910.Y14
D322
BB 639 SOD323 ................................... Diode ............................................. 351-26571
D337
BYT 13-1000 RM15 ............................... Diode ............................................. 352-22712
D341
BB 639 SOD323 ................................... Diode ............................................. 351-26571
D342
STTA506F TO220 ................................. Diode ............................................. 352-27866
D403
BB 535 SOD323 ................................... Diode ............................................. 351-26570
D422
BB 535 SOD323 ................................... Diode ............................................. 351-26570
D441
BB 535 SOD323 ................................... Diode ............................................. 351-26570
D474
1 N 4148 DO35 ..................................... Diode ............................................. 352-31818
D505
STTA806D TO220 ................................. Diode ............................................. 352-27622
D506
STTA806D TO220 ................................. Diode ............................................. 352-27622
D508
BB 640 SOD323 ................................... Diode ............................................. 351-26568
D512
STTA806D TO220 ................................. Diode ............................................. 352-27622
D513
STTA806D TO220 ................................. Diode ............................................. 352-27622
D518
STTA806D TO220 ................................. Diode ............................................. 352-27622
D519
STTA806D TO220 ................................. Diode ............................................. 352-27622
D522
STTB812FI VORM. .............................. Diode ............................................. 352-27867.050
D527
BB 639 SOD323 ................................... Diode ............................................. 351-26571
D551
BB 535 SOD323 ................................... Diode ............................................. 351-26570
D624
BYT 13-1000 RM15 ............................... Diode ............................................. 352-22712
D651
BA 157 .................................................. Diode ............................................. 352-44799
D656
BY 398 RM17,5 .................................... Diode ............................................. 352-11109
Art.-Nr. 87953.050
Description
Bestell-Nr.
List Part N
SOCKETS
TRANSISTORS
DIODES
DIODES
Basic Board Plasma CTV
Pos.Nr. Bestell-Bezeichnung
°
°
.
Item N
.
D656
BY 398-GP FAGOR .............................. Diode ............................................. 352-23358
D661
10A 200V ISOWATT220AC ................. Diode ............................................. 352-28625
050
D671
STPS20L40CF geschnitten/gebogen .... Diode ............................................. 352-20296.Y20
D681
BA 157 .................................................. Diode ............................................. 352-44799
050
D686
BY 398 RM17,5 .................................... Diode ............................................. 352-11109
050
D686
BY 398-GP FAGOR .............................. Diode ............................................. 352-23358
050
D687
BY 398 RM17,5 .................................... Diode ............................................. 352-11109
050
D687
BY 398-GP FAGOR .............................. Diode ............................................. 352-23358
050
D806
BAV 99W SOT323 ............................... Diode ............................................. 351-27469
050
QUARZE/FILTER
050
X651
4,000000 MHz HC49U3 low profile ....... Crystal Oscillator ........................... 385-27752
050
X701
OFW K 6263 K ...................................... Filter .............................................. 290-25214
050
POTENTIOMETER ............................................. POTENTIOMETERS
050
P542
1K .......................................................... Potentiometer ................................ 375-18289
050
P543
4K7 ........................................................ Potentiometer ................................ 375-15974
050
SICHERUNGEN
F317
6300mA T 250V 5x20 ............................ Fuse .............................................. 380-28271
050
F656
1250mA T 250V 8x8 .............................. Fuse .............................................. 380-17123.020
050
F661
2500mA T 250V 8x8 .............................. Fuse .............................................. 380-15825.020
050
F672
5000mA T 250V 8x8 .............................. Fuse .............................................. 380-27665.020
050
F689
630mA T 250V 8x8 ................................ Fuse .............................................. 380-13837.020
050
KONDENSATOREN
C311
2N2 M 400VW ...................................... Capacitor ....................................... 357-14192.Y02
050
C312
220N M 275VW .................................... Capacitor ....................................... 359-77769
050
C314
470N M 275VW .................................... Capacitor ....................................... 359-28292
050
C316
470N M 275VW .................................... Capacitor ....................................... 359-28292
050
C317
470N M 275VW .................................... Capacitor ....................................... 359-28292
050
C337
470P K1000V ....................................... Capacitor ....................................... 357-23994.020
050
C339
470P K1000V ....................................... Capacitor ....................................... 357-23994.020
050
C342
Elko 330U M 450V .............................. Electrolytic Capacitor ..................... 360-27891
050
C467
470P K1000V ....................................... Capacitor ....................................... 357-23994.020
050
C469
470P K1000V ....................................... Capacitor ....................................... 357-23994.020
050
C505
820P J1600V ........................................ Capacitor ....................................... 359-26529
050
C506
820P J1600V ........................................ Capacitor ....................................... 359-26529
050
C507
Elko 330U M 450V .............................. Electrolytic Capacitor ..................... 360-27891
050
C512
330P K 2000V ...................................... Capacitor ....................................... 359-28860
050
C521
100P K 2000V ...................................... Capacitor ....................................... 359-28861
050
C522
10N M1000V ........................................ Capacitor ....................................... 359-22573
050
C531
1000U M250V ...................................... Electrolytic Capacitor ..................... 360-27506
050
C532
100N M 250VW .................................... Capacitor ....................................... 359-23372
050
C626
10N M1000V ........................................ Capacitor ....................................... 359-22573
050
C672
Elko 6800U ........................................... Electrolytic Capacitor ..................... 360-27120.040
050
C677
Elko 6800U ........................................... Electrolytic Capacitor ..................... 360-27120.040
050
C679
Elko 6800U ........................................... Electrolytic Capacitor ..................... 360-27120.040
050
C682
680P K 500V ........................................ Capacitor ....................................... 357-21183020
050
050
050
3 - 6
Art.-Nr. 87953.050
Description
Bestell-Nr.
List Part N
QUARTZES/ FILTERS
FUSES
CAPACITORS
°
.
