Any problem, please feel free to contact us.

USB 2.0 Port

The USB port supports the USB 2.0 specification. Use this port for USB devices.

USB 3.0 Port

The USB 3.0 supports the USB 3.0 specification and is compatible to the USB 2.0
specification. Use this port for USB devices.

VGA Port

VGA (Video Graphics Array) supports analog video signal transmission, high resolution, fast
display rate and rich colors.

DVI Port

DVI (Digital Video Interface) is a dedicated digital interface suitable for image transmission,
with high speed and clear picture.

HDMI Port

The HDMI port supports 4K and 1080px. You can use this port to connect your
HDMI-supported monitor.

RJ45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 1000Mbps/s data rate.
The following describes the states of the LAN port LEDs.

PS/2 Port

This PS/2 port can be connected to a keyboard or mouse.
6
