Engine Support with 4-point support
COMPONENTS
1 Horizontal beam
2 Pull spindle carrier with spindle, spindle nut
3 Support feet for shock absorber
4 Outriggers for fender mounting
5 Longitudinal beam
6 Support feet for lock carrier
7 Chain and shackle
SPECIFICATIONS
Max. capacity: 315 kg
Cross beam width: 1500 mm
Longitudinal beam length: 510 - 845 mm
Pulling spindle length: 340 mm
Chain length: 530 mm
ATTENTION
Read the operating instructions and all safety instructions contained therein carefully before using the
product. Use the product correctly, with care and only according to the intended purpose. Non-
compliance of the safety instructions may lead to damage, personal injury and to termination of the
warranty. Keep these instructions in a safe and dry location for future reference. Enclose the
operating instructions when handing over the product to third parties.

INTENDED USE

This device was developed for a safe and secure engine support. The engine will be supported by
front drive gears during and after its. The firm and rugged construction of the device prevents from
twisting and distorting of the beams. Following standards leads to safety, firmness and stability.
