S.E. System Electronic 300E-1800BK Original Montage- Und Gebrauchsanleitung Seite 41

A > 30 cm zur Wand
> 80 cm zu weiterem Hs
B > 30 cm zur Wand
> 300 cm zu weiterem Hs
6.2 Special conditions cord suspension
Stand 07/2014
- 41 -
C
D
C > 6 cm
D > 210 cm
Distance between wall and heater
Distance X must be at least as long as the
length of the suspension, plus 80 cm.
No ammable objects may be placed within
the pivoting range.
The radiant heater is meant to be a vertically
hanging system and its position, xed by force
of gravity, may by no means be changed.
The radiant heater and its cord system may not
be mounted onto mobile objects In addition to
that the device must not swing up.
E
F
A
B
F > 20 cm
TREME
INE
EN
C
B
