RaidSonic Icy Box IB-RD2253-C31 Handbuch Seite 12

Manual IB-RD2253-C31
ATTENTION: After each change of the RAID mode (pressing the "RESET"
button), the disk(s) in the system must be reinitialized and reformatted.
To initialise and format the data media, open the data media management of your
operating system and carry out the initialisation and formatting.
SINGLE - NORMAL
Both SSDs are integrated as independent drives with
their own content, independent of each other.
JBOD (LARGE) - BIG
Both SSDs are combined into a single logical vo-
lume without redundancy. JBOD is used to simplify
access to multiple hard drives.
RAID 1 (Mirroring) - SAFE
Both SSDs store the same data, creating redun-
dancy.
If one SSD fails, all data is still stored on the second
SSD.
RAID 0 (Striping) - SPEED
The data is distributed (striped) to both SSDs, which
increases the access speed because both SSDs are
accessed simultaneously.
ATTENTION! If one SSD fails, all data is lost!
