3.4 Attaching the seal - Integrated
installation
1. Clean the rabbets in the worktop.
2. Cut the supplied 3x10mm seal stripe into
4 stripes. The stripes must have the
same length as the rabbets.
3. Cut the ends of the stripes at an angle of
45°. They should fit in the corners of the
rabbets accurately.
4. Attach the stripes to the rabbets. Do not
stretch the stripes. Do not bond the ends
of the stripes one over the other.
After you assemble the hob, seal the
remaining gap between the glass ceramic
and the worktop with silicone. Make sure the
silicone does not get under the glass
ceramic.
3.5 Attaching the seal - On-top
installation
1. Clean the worktop around the cut out
area.
2. Attach the supplied 2x6mm seal stripe to
the lower edge of the hob, along the
outer edge of the glass ceramic. Do not
stretch it. Make sure that the ends of the
seal stripe are located in the middle of
one side of the hob.
3. Add some millimetres to the length when
you cut the seal stripe.
4. Join the two ends of the seal stripe
together.
3.6 Assembly
If you install the hob under a hood, please
see the installation instructions of the hood
for the minimum distance between the
appliances.
8 ENGLISH
min.
500mm
If the appliance is installed above a drawer,
the hob ventilation can warm up the items
stored in the drawer during the cooking
process.
ON-TOP INSTALLATION
580
min.
50mm
510
44
