Aktion am Sender
T1 mit GND verbinden
T2 mit GND verbinden
T3 mit GND verbinden
T4 mit GND verbinden
T1 mit GND verbinden
T2 mit GND verbinden
T3 mit GND verbinden
T4 mit GND verbinden
T1 von GND trennen
T2 von GND trennen
T3 von GND trennen
T4 von GND trennen
Frequenzwechsel
In seltenen Fällen kann es vorkommen, dass die werkseitig eingestellte Frequenz durch andere Funkgeräte gestört wird. In diesem Fall
können Sie mit dem Schalter (siehe Abbildung) auf die zweite Arbeitsfrequenz (f2) umstellen. Der dazugehörige Empfänger muss dann
ebenfalls auf die zweite Frequenz umgestellt werden (siehe Anleitung Empfänger).
6
Technische Daten
Arbeitsfrequenz:
Antenne:
Versorgung:
Stromaufnahme:
Temperaturbereich:
Anschlüsse:
Gehäuse:
Fixed UHF Transmitter
Please read carefully!
These operating instructions form an integral part of this product and contain important information on how to commission, install and
operate it. They must be taken into consideration and given to the end user or other third party when the installer hands over the
product. These operating instructions must be retained for future reference.
Damage resulting from abuse or misuse is not covered by warranty. The manufacturer accepts no warranty for consequential losses
that may result directly or indirectly from use of this equipment. Any changes or modifications not expressly approved by the party
responsible for compliance could void the user´s authority to operate the equipment.
The product meets the requirements of the current European and national guidelines for electromagnetic compatibility. Conformity has
been established and the relevant statements and documents have been deposited at the manufacturer.
1
Mode of operation
The fixed radio ransmitter SHT-12 FS can be controlled by up to 4 floating contacts. The state of the floating contacts will be encoded
and transmit via radio frequencies to the SH-12 receiver, e.g. SHR-12 K4. The operation corresponding to these signals depends on
the receiver and its wiring.
It should be noted that for applications that could put human life at risk, by using radio connection there is always
present a potential hazard due to extraneous disturbances.
The Operating Instructions need to be followed at all times.
2

Safety Precautions

Ensure that the product is isolated from any power supply before opening. Opening and installation of the product
must be performed only by a qualified electrician.
Further safety precautions
Every applicable regulations and standards have to be observed, in particular VDE0100, VDE0550/0551, VDE0700, VDE0711 and
VDE0860. The use of solid cables for connection is recommended since terminal design does not incorporate stress relief. The
product corresponds to Safety-Class II (without protective earth terminal) according to VDE0700, IEC335EN60335.
For commercial use, compliance must be made with the recommendations and instructions of the responsible regional/national
authorities.
For use in public institutions, schools, clubs and do-it-yourself workshops the operation of this product has to be supervised by
qualified personnel.
We do not assume any warranty and liability for personal or material damages caused by incorrect application or by failure to follow
these operating instructions.
DIP-Schalter Funktionsauswahl
1=ON / 5 = OFF
2=ON / 6 = OFF
3=ON / 7 = OFF
4=ON / 8 = OFF
5=ON / 1 = OFF
6=ON / 2 = OFF
7=ON / 3 = OFF
8=ON / 4 = OFF
5=ON / 1 = OFF
6=ON / 2 = OFF
7=ON / 3 = OFF
8=ON / 4 = OFF
f1 433,62 MHz; f2 434,22 MHz
Integrierte Antenne
4,5 – 24,0 V DC ; 12V AC
Stand By 0,1mA; Regulärer Sendebetrieb 8,5mA (im Mittel)
-20
o
C bis +65
o
C
Schraubklemmen innenliegend
130 mm x 85 mm x 37mm, Schutzart IP54
Empfänger-Information
T1
T2
T3
T4
T1
T2
T3
T4
T5 (Auswertung nur mit SHR-12 K4)
T6 (Auswertung nur mit SHR-12 K4)
T7 (Auswertung nur mit SHR-12 K4)
T8 (Auswertung nur mit SHR-12 K4)
Operating Instructions
-
-
3
Modulausgänge
OUT1
OUT2
OUT3
OUT4
OUT1
OUT2
OUT3
OUT4
OUT2 + OUT4
OUT2 + OUT3
OUT2 + OUT3 + OUT4
OUT1 + OUT2
(D –
GB
F)
