EN
Mounting instructions
DE
Montageanleitung
FR
Notice de montage
IT
Istruzioni di montaggio
NL
Montagehandleiding
PANOS INF R100V
E13270
E13271
TYP
Thorn Lighting Limited
Durhamgate Spennymoor
Co. Durham DL16 6HL UK
EN
Important notices. Please, read first!
DE
Wichtige Hinweise. Bitte zuerst lesen!
FR
Remarques importantes. À lire en premier lieu !
IT
Note importanti. Si prega di leggere prima!
NL
Belangrijke informatie. Gelieve eerst te lezen!
1
2
The installation and commissioning of the luminaire as well as any modification to the luminaire may only be performed
1
EN
by authorized personnel (qualified electrician).
The manufacturer is not liable for damages resulting from improper or faulty installation or operation or from unauthorized
modifications to the luminaire.
The luminaire is used exclusively for lighting and is to be installed in accordance with the national installation regulations.
Use of the supplied control gear only in conjunction with the associated luminaire
2
Caution, risk of electric shock! Disconnect mains cables and any existing DALI control lines from mains and check that
the power is off before conducting any maintenance and assembly work.
Hot plug-in is not permitted. Hot plug-in may result in damage to the luminaire and entail loss of warranty claims!
Neutral conductor breaks during operation will result in power surge damage to the lighting system. Therefore neutral disconnect
terminals in three-phase AC circuits may only be opened voltage-free and must be closed before power supply is switched back on.
Luminaire not suitable for covering with thermally insulating material.
3
The luminaire is protection type IP44, only when being installed in an enclosed ceiling! Protection type IP44
4
does not apply in the ceiling void itself.
With thin or soft ceiling material it is recommended that ceiling reinforcing rings or frames should be used to enlarge the
5
bearing surface.
Commissioning after the construction phase, if the mains voltage is continuously present !
Dispose of packaging and luminaire in accordance with applicable regional regulations.
6
Keep the instructions safe!
Specifications are subject to change without notice! If you have questions, please contact the manufacturer.
1/8
NO/SV
Installationsanvisning
FI
Asennusohje
ES
Instrucciones de montaje
安装说明
ZH
RU
Инструкция по монтажу
E14522 E14596
3
4
IP20
IP44
Zumtobel LIGHTING GmbH
Schweizerstrasse 30
6850 Dornbirn AUSTRIA
NO/SV
1
FI
2
ES
2
ZH
2
RU
3
5
6
60800313
www.Zumtobel.com
Zumtobel Lighting GmbH
Schweizerstrasse 30
6850 Dornbirn AUSTRIA
..W LED..(...mA)
220-240V 0/50/60Hz
Viktigt information. Läs först!
Tärkeä huomautus. Lue ensin!
Notas importantes. Por favor, lea primero!
重要提示。请先阅读!
Важная информация. Просьба
ознакомиться перед началом работ!
Mat.-Nr: 06 979 932/4/00 10.21
IP20
IP44
3
3
4
4
4
