EN
ACDB-8000AC PLUG-IN WIRELESS DOORBELL SET
A
LED indicator doorbell
B
Connect button
C
Volume button
D
Melody selection
E
LED indicator push button
F
Push button
Wireless control
The wireless doorbell can be operated wirelessly with
a minimum of 1 and a maximum of 32 Trust Smart
Home transmitters of your choice. For example, you can
play a desired melody using the supplied push button.
In addition, you can also play a melody when movement
is detected and / or when a window or door is opened.
For each Trust Smart Home transmitter you can set
a separate melody to hear exactly whether someone
presses the push button or if a door or window is opened.
1. Remove battery strip from push button
A
Insert a flat screwdriver into the notch at the bottom
of the push button and slide the push button off the
back plate.
B
Open the waterproof rubber by flipping it to reveal
the battery.
C
Remove the plastic battery strip.
D
Close the waterproof rubber and place the push button
back on the back plate.
2. Placing the Receiver
Place the doorbell in an indoor electrical outlet. If you
move the doorbell to another outlet, the connected
transmitters will remain in the memory.
3. Selecting the desired volume
First press the volume button to set the desired volume
8
level. There are 4 levels: High, Medium, Low and Off
(LED indication only).
4. Selecting the desired melody
Press the melody button to select 1 of the 6 melodies.
You can set a separate melody for each transmitter
(push button, motion detector, door/window sensor)
by selecting it in advance.
5A. Connecting transmitter(s) to the doorbell
Press the connect button for 1 second to activate the
learning mode.
The learning mode will be active for 10 seconds and the
LED indicator on the doorbell will flash slowly.
5B
While the LED indicator is flashing, send an ON signal with
a Trust Smart Home transmitter to pair it to the doorbell.
5C
As soon as the transmitter is paired, the wireless doorbell
will give 2 short beeps. The transmitter, melody and
volume are now paired. The wireless doorbell is now ready
for use. The receiver can store 32 different transmitters in
its memory. If you want to pair several transmitters, repeat
steps 2 to 5c.
6A. Securing push button with double-sided tape
Determine where to place the push button and attach the
push button with the supplied double-sided tape.
6B. Securing push button with screws
A
Insert a flathead screwdriver into the notch on the
bottom of the push button and slide the push button
off the back plate
