2. Before installing please clean the
surface where camera is to be
positioned
3. Drill a hole in the lamp ca-
sing above the license plate
and run the camera cable
through it.
4. Remove the protective side of the adhesive tape on the back of
the camera. Stick the camera in the desired position.
5. The outer housing can also be fixed to the car by screws (not
included).
PRODUCT FEATURES
Easy to install | Housing can be lacquered as required
SPECIFICATIONS
Image sensor:
Viewing angle:
Lens:
Signal system:
Resolution:
Frame rate:
Min illumination:
Operating Voltage:
Current draw:
Operating temperature:
IP rating:
Fuse:
The camera RVC1 is not suitable for long-term usage.
GB
CMOS
170°
EFL = 1.8 mm
PAL
720 H x 576 V
30 fps
0.5 Lux
9 - 16 V DC
<150 mA
-30 °C – +70 °C
IP 67
T 100 mA L/250 V
