INSTALLATION INSTRUCTIONS

AV cable
Reverse drive wire
Back-up light
power supply
Please follow the instructions to
install the camera.
A. Install the camera in the close to the license plate
lamp, connect to the reverse power wire.
B. Please install the camera cable along the red line as
shown on the picture (1.) to the center console monitor.
- +
C. Please follow the instructions on the monitor to
connect the AV line and reverse drive
wire.
HOW TO ASSEMBLE
1. Outer housing
2. 3M double-sided adhesive
3. Camera
4. Screws
STANDARD ASSEMBLY METHOD
1. Install the camera close to the
license plate lamp, approx.
56 cm above ground level
GB
3
(1)
