detach the bead from the rim).
14 Deflation button (button to remove the
extra air inside the wheel).
15 Pressure gauge (reads the wheel
pressure).
16 Rim rest.
17 Safety relief valve (max. pressure 12 bar)
(TI versions only).
18 Filter Regulator + Lubricator Unit (regu-
lates pressure, filters, removes humid-
ity of and lubricates the compressed air
24
15
º
14
3
25
12
Operator's manual M 824 LL
A
6
20
7
4
11
8
9 10
supply).
19 Lube bottle.
20 Inflation nozzles (air introduced
through these nozzles pushes the
beads outward to form a seal and per-
mit inflation) (TI version only).
21 Air tank (TI version only).
22 Shoe guard.
23 LL head control valve.
24 Hook actuator cylinder.
25 Doyfe connector (fits onto tyre valve for
1
23
5
18
13
22
16
2
B
17
21
19
