1. INSTALLING THE INTEL BACKPLATE
D
2. INSTALLING THE INTEL STANDOFF SCREWS
ENGLISH
Adjust backplate for your required socket.
NOTE: Intel LGA 2066/2011-3/2011
do not require backplate installation.
Proceed to step 2.
> Attach the provided Intel standoff for
LGA 1200/
A
1150/1151/
> Use (A) for LGA 1200/115X, (B) for
1155/1156
> Tighten all four standoffs until
LGA 2011/
B
2011-3/2066
LGA 1700
C
2
your socket.
LGA 2011/2011-3/2066 or (C) for LGA 1700.
firmly secured.
