1. .Click
to import vector files in the formats of PLT, DWG and Al;
2. The vector files imported must be flled before carving.
There is no need to set other parameters for filling of vector files. Only "line" needs
to be changed. The default value is 0.04
Notes:"Line" is the text filling density. The greater the value, the higher the
carving speed, the lighter the carving color; the smaller the value, the lower the
carving speed, the deeper the carving color;
Carving on primary color metal, paint and baking paint, oxidized paint surface,
electroplated metal, plastic, leather and other paint materials provide the best
effects.
Part 16：Mark Control
Recommended
Parameter Adjustment
Speed(mm/s):500
power(%):100
Frequency(KHZ):30
Red light (F1):
Preview the current
carving position, red
light rectangular
preview mode
Mark(F2): Start
carving
The option is
checked to set as the
contour preview
mode.
