• Check for electric lines or pipes, or metal studs in wood battens.
• Make sure the holes are level.
• Pre-drill the holes (± 30mm deep) using a power drill and a 3mm wood bit.
• Fix both plates [A & B] to the wall using two lag bolts [W-A].
Note: mount the left plate [A] in the left position and the right plate [B] in the right.
1b Concrete or Brick Support
• Choose an installation spot able to support the weight of the screen.
• Use the wall template [F] to mark the three hole locations:
o Stick the double sided adhesives [E] to the back of the wall template [F].
o Peel off the protective paper and stick the template to the wall.
o Mark the holes and remove the template.
• Check for electric lines or pipes.
• Make sure the holes are level.
• Drill the holes (± 60mm deep) using a power drill and a 10mm masonry bit.
• Insert a nylon plug [W-B] in each hole.
• Fix both plates [A & B] to the wall using three lag bolts [W-A].
Note: mount the left plate [A] in the left position and the right plate [B] in the right.
2 Mounting the brackets on the LCD
• Mount the adaptor brackets [C] (upper positions) and supporting spacers [D] (lower
positions) on the back of the screen using the appropriate M4, M5, M6 or M8 screws and the
appropriate washers (see diagram 2a):
o Start with the shortest possible screw and screw it into the mounting hole. The screw must
make at least 3 full turns. If not, select a longer screw.
o You might need to use spacers or extra washers [M-M or M-N] with LCDs with curved or
recessed back panels (see diagram 2b & 2c).
3 Mounting the LCD onto the brackets
• Hook both adaptor brackets [C] over the wall brackets as illustrated (see diagram 3).
Note: this operation should be done by 2 adult persons!
4 Level the LCD
• To adjust the horizontal angle, firmly hold opposite angles of the display and gently move it
into the desired position.
Note: check all screws and brackets regularly to ensure safe use.

7. Technical specifications

Use this device with original accessories only. Velleman nv cannot be held responsible in
the event of damage or injury resulted from (incorrect) use of this device.
For more info concerning this product and the latest version of this user manual, please
visit our website www.velleman.eu.
The information in this manual is subject to change without prior notice.
1. Inleiding
Dank u voor uw aankoop! Lees deze handleiding grondig voor u het toestel in gebruik neemt. Werd
het toestel beschadigd tijdens het transport, installeer het dan niet en raadpleeg uw dealer.

2. Veiligheidsinstructies

• De garantie geldt niet voor schade door het negeren van bepaalde richtlijnen in deze handleiding
en uw dealer zal de verantwoordelijkheid afwijzen voor defecten of problemen die hier
rechtstreeks verband mee houden.
• Schade door wijzigingen die de gebruiker heeft aangebracht valt niet onder de garantie.
• Gebruik het toestel enkel waarvoor het gemaakt is. Bij onoordeelkundig gebruik vervalt de
garantie.
• Gebruik geschikt gereedschap dat beschadigd of vervormd is.
• De meegeleverde pluggen en schroeven zijn enkel geschikt voor montage op baksteen, beton of
23/09/2011
LCD/plasma size
max. load
rotation
TV to wall
GEBRUIKERSHANDLEIDING
WB033
13"- 52"/ 33cm - 132 cm
40 kg / 88 lbs
-3° ~+3°
14.5mm
7
