Worcraft PROFESSIONAL CJS-S20LiB Übersetzung Der Original-Gebrauchsanweisung Seite 56

Part No Part Name
1 BL motor & controller system
2 Motor gear
3 6000 ball bearing
4 Aluminum bracket
5 Pendulum block
6 Balance block
7 Washer
8 Big gear
9 Reciprocating pole bushings
10 Needle bearing
11 Snap ring
12 Reciprocating pole bracket
13 Guide bracket
14 Reciprocating pole
15 Elasticity washer
16 Location seat
17 Transparent cover
18 Pendulum knob
19 Location limit pin
20 Pendulum Spring
21 Steel ball
22 Decoration block (left)
23 Switch button
24 Left housing
25 Switch pole
26 Spring
27 Guide roller assembly
28 Protection steel wire
29 Location pin
PARTS LIST CJS-S20LiB
Qty
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
Part No Part Name
30 Guide roller location bushings
31 Wind spacer block
32 Right housing
33 Blow / suction shift button
34 Cross head screw
35 Rubber pad
36 Fixing block
37 LED light seat
38 Location limit block
39 Balseplate lock pole
40 Lock pole knob
41 Right battery seat housing
42 Battery connetion seat
43 Left battery seat housing
44 Guide fence Lock knob
45 Spring for lock knob
46 Baseplate
47 Nylon baseplate cover
48 Anti-splinter block
49 Cross head screw
50 Baseplate fixing block
51 Hex bolt
52 Battery pack
53 Saw blade
54 Suction tube
55 Adaptor tube
56 Rip guide fence
57 Battery charger
Qty
1
1
1
1
13
4
1
1
1
1
1
1
1
1
2
2
1
1
1
6
1
1
1
1
1
1
1
1
