CORDLESS JIGSAW
IINTENDED USE
This appliance is suitable for straight and curved cutting as well as mitre cuts of up to 45° on angular workpieces made of
plastic, wood and light metal. This appliance is exclusively intended for private use in dry indoor spaces. Observe the guidelines
on saw blade types. Any other usage of or modification to the appliance is deemed to be improper and carries significant risk of
accidents. The manufacturer shall assume no liability for damage attributable to misuse.

TECHNICAL SPECIFICATIONS

Model CJS-S20LiB (ZS-881603)
Voltage 20Vd.c.
Speed 800-3800 /min
Pendulum settings 0/1/2/3
Cutting capacity Wood: 135mm
Steel: 10mm
Aluminum: 20mm
NOISE/VIBRATION INFORMATION
The vibration level given in this information sheet has been measured in accordance with a standardised test given in EN 62841
and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is poorly maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when it
is running but not actually doing the job. This may significantly reduce the exposure level over the total working period. Identify
additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the accessories,
keep the hands warm, organisation of work patterns.
EXPLANATION OF SYMBOLS
Attention!
Read the manual.
Wear eye protection
Electrical
disposed of with the domestic waste.
PRODUCT ELEMENTS (see fig. 1)
1 Speed adjustment wheel
3 Dust exhaust port
5 Pendulum selector knob
7 Protection pin
9 Protection cover
11 Quick release lever for baseplate
13 SDS chuck
15 Saw blade
17 Anti-splinter guard
SAFETY
General Power Tool Safety Warnings
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your
mainsoperated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
●
Keep work area clean and well lit. Cluttered or dark
appliances must not
Insulation class
Recommended battery pack
Declared sound pressure level
Declared sound power level
Vibration (on borad)
Vibration (on metal)
Weight:
Always remove the battery before maintainance or any
adjustment.
Wear ear protection.
Wear breathing protection
be Compliance with the relevant requirements of EU
directives).
2 Switch knob
4 Dust blow / suctioin selector switch
6 Base plate
8 LED working light
10 Lock screw knob for guide fence
12 Blade guide roller
14 Rip guide fence
16 Dust connection adaptor
areasinvite accidents.
●
Do not operate power tools in explosive atmospheres, such
as in the presence of flammable liquids, gases ordust. Power
tools create sparks which may ignite the dust or fumes.
●
Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.
Electrical safety
●
Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
III
CLB-20V-4.0/CLB-20V-4.0H
LpA: 78dB(A), KpA=5dB(A)
LwA: 89dB(A), KwA=5dB(A)
2
a =11,18m/s , K=1.5m/s
h,B
2
a =8,13m/s , K=1.5m/s
h,M
1.65kg
2
2
