Mobile use
Unpack the LED IP FL-20 Floodlight and carry the device via the comfortable handle to the desired place for
use.
Place the LED IP FL-20 Floodlight on a flat surface, adjust the desired inclination-angle and tighten the
fixation screws.
OPERATION
Open the rubber seal of the DC IN-socket on the backside of the device.
Connect the connection cable of the power-unit with the DC IN-socket. Plug the power unit into your outlet.
The battery pack recharging time is approximately 5 hours; when fully charged, the device can be operated
for approximately 3 hours.
Please note: The indicator light (two-colored LED )next to the on/off push button indicates much information.
- The indicator light blinks red and green means the battery pack is being charged.
- The indicator light shows a steady green means the battery pack is fully charged.
- During operation of the luminaire the indicator light is off.
- A slow blinking means the battery pack capacity has dropped to 10%.
- A fast blinking means the battery pack capacity has dropped to 5%.
Disconnect the power-unit with connection cable, close the rubber seal of the DC IN-socket, and install the
device as desired (description under INSTALLATION).
Via the on/off push button, you can turn the device on .The internal color-switch-program begins ("Flash").
Via the enclosed IR remote control, you can adjust the brightness of the static colors. You can also choose
from 4 internal programs.
Danger of explosion when battery is replaced improperly. Only replace by the same type.
Remote control
The remote control is supplied with battery inserted.
1
An insulating foil between the battery and the battery contacts prevents the battery from being
2
discharged during storage. Prior to the first operation remove the foil from the battery support on the
rear of the remote control. Otherwise operation of the remote control is not possible.
When pressing a button, always hold the remote control in the direction of the sensor. There must be
3
visual connection between the remote control and the sensor.
If the range of the remote control (a maximum of 3 meters) decreases,
4
replace the battery. For this purpose, on the rear of the remote control press
the small bar with the groove to the right (1) and at the same time remove the
battery support (2).
For operation, one 3 V button cell type CR 2025 is required. When inserting, pay attention that the
5
positive pole of the button cell is facing upwards in the support.
Batteries are hazardous waste and should not be disposed of with regular domestic waste!
Please take old and used batteries to a collection center near you.
CAUTION! The power unit was designed for indoor use only.
Please recharge the LED IP FL-20 COB RGB indoors only.
BATTERY DISPOSAL NOTICE
Please dispose of old and used batteries properly.
CAUTION!
10/12
00078075.DOC, Version 1.1
