IP CONFIGURATION

The automatic network configuration via DHCP is activated in the delivery state. To configure the network manually, go to the settings and change
the „Ethernet IP mode" to „static" (Settings -> Network & Internet -> Ethernet -> Ethernet IP Mode -> static -> Configure IP etc.) . Restart the unit
after changing the status.

TECHNICAL DATA

Article number
Product type
Type
Processor
Working memory
Internal memory
Operating controls
Display resolution
Display brightness
Touch Panel Type
Mounting position
Operating system
Connections
Card reader
Network
Power supply
Mounting options
Dimensions (W x H x D)
Weight
Ambient temperature
Relative air humidity
Accessories (optional)
Accessories included
LDQTP8
Installation equipment
8" QUESTRA touch panel, PoE powered
RK3566 – Quad-core up to 1.8 GHz
2 GB
16 GB
8" touch display, set, restart
1280 x 800 Pixel
300 nits
5-points capacitive IPS touch panel
Landscape or portrait format (landscape format recommended)
Android 11
Ethernet RJ45, Power In, RS485 (currently without function), USB-C
TF Card / MicroSD
2.4G WIFI, BT 4.0, 10M/100M Ethernet
PoE+ (Power over Ethernet), IEEE 802.3at compliant, external power supply 12 V DC 2 A (optionally available)
EU flush-mounted box, US 2-gang electrical box, 86-type electrical box
200 mm x 124.6 mm x 37.7 mm
0.45 kg
0 – 40°C
<80%, non-condensing
Power supply
Mounting plate plus locking screw
