INSTALLATION

Electric connection

Mounting the cooker hood

EN 10
Electric connection
The appliance has been manufactured as a class II, therefore no earth
cable is necessary.
Make sure the supply voltage ratings correspond with those stated on
the appliance data plate. The connection to the mains is carried out as
follows:
BROWN = phase L
BLUE = phase N
This cooker hood has been provided with a power plug. When installing
the hood, make sure that this plug remains accessible. We recommend
installing the wall socket out of view, behind the chimney cover.
Attention:
If you want to make a fixed connection, ensure that a multi-pole switch
with a distance between contacts of 3 mm is installed in the supply
cable.
The last pages of this manual show the steps for mounting the
cooker hood.
120 cm
