ABST-604 WIRELESS DUSK/DAWN SENSOR
EN
1. Install transmitter batteries
1. Detach the foot stand with a screwdriver.
2. Remove the screws to open the battery compartment.
3. Place 2x 1,5V AAA alkaline batteries in the battery compartments. The polarity should match the
symbols on the holder.
2. Assign code to a Trust Smart Home receiver
Program the code of this transmitter into the memory of one or several Trust Smart Home receivers.
Slide the LEARN switch from [DEL] to [SET] to send an ON-signal. Read the receiver's manual for the
code learning procedure.
3. Set switch-off delay
At the "0" setting, the transmitter will send an OFF-signal once a certain light level has been reached
(see: "Set light level"). At the 2h-8h setting, the transmitter will automatically send an OFF-signal after
2 up to 8 hours after the ON-signal.
4. Close battery cover and snap on the foot stand
Tighten all screws to ensure waterproofness. Damaging or removing the rubber seal inside the
housing can lead to leakage.
5. Set light level for the ON signal
To set the light level, press and hold the [START] button for 3 seconds. The current light level will be
stored and the LED on the front will flash 16 times. When the sensor registers the set light level, it will
send an ON signal to the receivers it has been assigned to.
6. Place transmitter indoor or outdoor
Use the foot for horizontal placement or use the rear slots for wall mounting. It takes approximately
30 seconds before the product is operational.
