Spezifikationen
Name
epc8025TrapCtrl
epc8025TrapIPIndex
epc8025TrapAddr
epc8025portNumber
epc8025PortIndex
epc8025PortName
epc8025PortState
epc8025PortSwitchCount
epc8025PortStartupMode
epc8025PortStartupDelay
epc8025PortRepowerTime
epc8025Buzzer
epc8025ActivePowerChan
epc8025PowerIndex
epc8025ChanStatus
epc8025AbsEnergyActive
epc8025PowerActive
epc8025Current
epc8025Voltage
epc8025Frequency
epc8025PowerFactor
epc8025Pangle
epc8025PowerApparent
epc8025PowerReactive
epc8025AbsEnergyReactive
epc8025AbsEnergyActiveResetta-
ble
epc8025AbsEnergyReactiveReset-
table
epc8025ResetTime
epc8025ForwEnergyActive
epc8025ForwEnergyReactive
epc8025ForwEnergyActiveReset-
table
epc8025ForwEnergyReactiveRe-
settable
57
Expert Power Control 8021/8025
OID
Description
.79.1.1.1.1.0
0 = off 1 = Ver. 1 2 = Ver. 2c 3 = Ver. 3
.79.1.1.1.2.1.1.x
A unique value, greater than zero, for each receiver slot.
.79.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.79.1.3.1.1.0
The number of Relay Ports
.79.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.79.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.79.1.3.1.2.1.3.x
current state of a Relay Port
.79.1.3.1.2.1.4.x
The total number of switch actions ocurred on a Relay Port. Does not
count switch commands which will not switch the ralay state, so just real
relay switches are displayed here.
.79.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.79.1.3.1.2.1.6.x
Delay in sec for startup action
.79.1.3.1.2.1.7.x
Delay in sec for repower port after switching off
.79.1.3.10.0
turn Buzzer on and off
.79.1.5.1.1.0
Number of suppported Power Channels.
.79.1.5.1.2.1.1.x
Index of Power Channel entries
.79.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.79.1.5.1.2.1.3.x
Absolute Active Energy counter.
.79.1.5.1.2.1.4.x
Active Power
.79.1.5.1.2.1.5.x
Actual Curent on Power Channel.
.79.1.5.1.2.1.6.x
Actual Voltage on Power Channel
.79.1.5.1.2.1.7.x
Frequency of Power Channel
.79.1.5.1.2.1.8.x
Power Factor of Channel between -1.0 and 1.00
.79.1.5.1.2.1.9.x
Phase Angle between Voltage and L Line Current between -180.0 and
180.0
.79.1.5.1.2.1.10.x
L Line Mean Apparent Power
.79.1.5.1.2.1.11.x
L Line Mean Reactive Power
.79.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.79.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all resetta-
ble counter.
.79.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.79.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.79.1.5.1.2.1.16.x
Forward Active Energy counter.
.79.1.5.1.2.1.17.x
Forward Reactive Energy counter.
.79.1.5.1.2.1.18.x
Resettable Forward Active Energy counter.
.79.1.5.1.2.1.19.x
Type Acc.
Integer32 RW
Integer32 RO
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
