vor der Mikrofonmembran tritt an Pin 2 eine positive
Spannung auf.
Der 3-polige XLR-Steckverbinder hat folgende Be-
legung:
Pin 1:
0 V/Masse
Pin 2:
Modulation (+Phase)
Pin 3:
Modulation (–Phase).

1.2 Mikrofonkabel

Für das KMR 82 i stehen folgende Kabel zur Ver-
fügung:
IC 3 mt ................. sw .............. Best.-Nr. 06543
Mikrofonkabel mit Doppeldrallumspinnung als Ab-
schirmung. Ø 5 mm, Länge 10 m. XLR 3 Steckverbin-
der, schwarzmatt.
Andere Kabellängen sind auf Wunsch lieferbar.
2.

Stromversorgung

2.1 Phantomspeisung

Das KMR 82 i wird mit 48 V phantomgespeist (P48,
IEC 61938).
Bei der Phantomspeisung fl ießt der Speisestrom
vom positiven Pol der Spannungsquelle über die
elektrische Mitte der beiden Modulationsadern zum
Mikrofon. Er wird hierzu über zwei gleichgroße Wi-
derstände beiden Tonadern gleichsinnig zugeführt.
Die Rückleitung des Gleichstroms erfolgt über den
Kabelschirm. Zwischen beiden Modulationsadern
besteht also keine Potentialdiff erenz. Daher ist mit
der Phantomspeisung eine kompatible Anschluss-
technik möglich:
Auf die Anschlussdosen können wahlweise auch
dynamische Mikrofone oder Bändchenmikrofone
sowie die Modulationskabel röhrenbestückter Kon-
densatormikrofone geschaltet werden, ohne dass die
Speisegleichspannung abgeschaltet werden muss.
Der Ausgang eines Neumann-Phantomspeisegerätes
darf auch auf bereits anderweitig phantomgespeiste
Mikrofoneingänge gesteckt werden.
2.2 Betrieb mit Netzgeräten
Für die Stromversorgung sind alle P48-Netzgeräte
geeignet, die mindestens 1 mA je Kanal abgeben.
4
sound pressure in front of the microphone dia-
phragm causes a positive voltage to appear at pin 2.
The 3-pin XLR connector has the following pin as-
signments:
Pin 1:
0 V/ground
Pin 2:
Modulation (+phase),
Pin 3:
Modulation (–phase).

1.2 Microphone Cables

The following cables are available for the KMR 82 i
microphone:
IC 3 mt ................ blk .............. Cat. No. 06543
Microphone cable with double twist (double helix)
braiding as shield. Ø 5 mm, length 10 m. XLR 3 con-
nectors, matte black.
Special cable lengths can be made to order.
2.

Power Supply

2.1 Phantom Powering

The KMR 82 i is phantom powered at 48 V (P48,
IEC 61938).
With phantom powering the dc from the positive
supply terminal is divided via two identical resis-
tors, one half of the dc fl owing through each audio
(modulation) conductor to the microphone, and
returning to the voltage source via the cable shield.
Phantom powering provides a fully compatible con-
necting system, since no potential diff erences exist
between the two audio conductors.
Studio outlets so powered will therefore also accept
dynamic microphones and ribbon microphones as
well as the modulation conductors of tube-equipped
condenser microphones without the need to switch
off the dc supply voltage.
No harm is done even if a Neumann phantom power
supply is connected to the inputs of microphones
which are phantom powered from another source.
2.2 ac Supply Operation
All P48 power supplies in accordance with
IEC 61938 which provide at least 1 mA per channel,
are suitable for powering the microphones.
