SYSTEM SETUP:
1
2
3
4
5
6
7
8
10
BODYPACK SETUP:
Full Display:
Displays battery status, RF/audio level, stereo/mono working
mode, EQ mode,locking status, limiter function and working
frequency, as shown in diagram
Left and Right Audio track Adjusting:
Press or to adjust left and right audio track balancing, as
shown in diagram . Please see the chapter "THE FOCUS MODE"
2
for further information.
Select a Group and Channel:
Repeatedly press "SET" button, until "GROUP" appears and
flashes. Press or to select suitable frequency group number,
as shown in diagram on the left. Press " SET" again until
3
"CHANNEL" flashes. Press
shown in diagram on the left.
4
Equalization setup:
Repeatedly press the "SET" button until "EQ" flashes. Press
to select the EQ working mode, Hight Boost (Offers more high-
end response: 6 dB boost at 10 kHz), Normal (Flat), as shown in
diagram .
5
Limiter selection:
Repeatedly press the "SET" button until "LIMITER" flashes and
press or to select the Limiter function, as shown in diagram
.
6
Locking selection:
Repeatedly press the "SET" button until "LOCK SELECT
hes. Press or to lock or unlock, as shown in diagram
When "LOCK SELECT" is activated settings in the transmitter can
be viewed but not changed.
Battery Indication:
The battery level is indicated in 4 stages
.
1
or to select a suitable channel, as
.
8
or
" flas-
.
7
