required direction. Then fix the
required position using the two
cross-head screws.
5 Depending on the installation
environment, it may be necessary
to change the door station speech
volume in order to permit clear
speech transmission.
6 Hook the front of the housing
onto the base plate at the top and
close. Tighten the screw on the
underneath of the housing.

Mounting in distribution cabinet

7 Mount the devices on the top
hat rail.
Lettering
8 Open the nameplate from the
outside, for example using a flat
bladed screwdriver, and carefully
remove the inscription insert. To
insert the nameplate, lock into place
by exerting light pressure.
Installation
9 Connect in accordance with the
relevant circuit diagram.
Note
a) The camera branch and monitor
branch must be laid separately and
must not be located in the same
cable. This can result in disturbance
to the picture composition.
Range
The In-Home bus must be installed
on one pair of cores when using
J-Y(St)Y, and when using a YR
conductor, on two YR cores posi-
tioned side by side. Using J-Y(St)Y
conductors reduces the likelihood of
interference.
SNG 850-... to door station max.
50 m,
SNG 850-... to the most remote
indoor device max. 50 m, with
0.8 mm core diameter.
With a core diameter of 0.6 mm, the
range is halved.
Terminal assignment
CV 850-1-...
TaK, TbK In-Home bus camera
branch
Tö (c) Relay contact door
release
Terminal assignment SG 150-...
TaM , TbM In-Home bus monitor
branch
+, - Supply voltage
20–50 V DC
ETb, ERT Storey call button
S1, S1 Potential-free contact
max. 30 V AC/DC, 2 A
E1, E1 galvanically isolated
4–30 V DC, 10 mA
PE, PE Equipotential bonding
LAN
Terminal assignment
NG 706-30/33-...
L1, N Power connection
+, - Output voltage
30 V DC
Terminal assignment SNG 850-...
L1, N Power connection
Ta, Tb In-Home bus
b, c Power supply 12 V AC
Tö, Tö Relay contact door
release
Li, Li Relay contact light
Specifications CV 850-1-...
Colour system: PAL
Image pick-up: CMOS sensor 1/3"
756 x 504 Pixel
Resolution: 550 TV lines
Lens: 3,7 mm
Pick-up angle: horizontal appr. 65°,
vertical appr. 50°
Mechanical adjustment range:
30° horizontal/vertical
Integrated LED lighting
2-step heating: 12 V AC,
max. 110 mA
Supply: via In-Home bus
Contact type: contact 24 V, 2 A
Protection system: IP 54, IK 8
Ambient temperature:
–20 °C to +40 °C
Dimensions (mm) W x H x D:
82 x 226 x 39
Specifications SG 150-...
Operating voltage: 20–50 V DC,
PoE in accordance with 802.3af
Operating current: max. 400 mA
Protection system: IP 20
Ambient temperature:
0 °C to +40 °C
Horizontal pitch (HP): 6
Dimensions (mm) W x H x D:
107 x 109 x 60
Specifications NG 706-30/33-...
Operating voltage: 230 V AC,
+/-10 %, 50/60 Hz
Operating current: 250 mA
Output voltage: 30 V DC
Output current: 1.1 A
Fusing: secondary side with thermal
fuse
Protection system: IP 20
Ambient temperature:
0 °C to +40 °C
Horizontal pitch (HP): 6
Dimensions (mm) W x H x D:
107 x 109 x 60
Specifications SNG 850-...
Operating voltage: 230 V AC,
+/-10 %, 50/60 Hz
Operating current: 200 mA
Output voltage: 27.5 V DC, 12 V AC
Output current: 0.5 A DC, 1 A AC
Fusing: Primary fuse 1 T 250 mA L,
secondary short circuit proof
Contact type: 2 n.o. contacts 24 V,
2 A
Protection system: IP 30
Ambient temperature:
0 °C to +40 °C
Horizontal pitch (HP): 9
Dimensions (mm) W x H x D:
162 x 89 x 60
