ASSEMBLY AND PROGRAMMING INSTRUCTIONS
EquaScan hMIU
Radio module for Itron UltraMaXX / UltraLite
thermal energy meter
SCOPE OF DELIVERY
• RF communication module
• User seal
GENERAL INFORMATION
The EquaScan hMIU
V2 serves to integrate the Itron UltraMaXX/UltraLite
RF
thermal energy meter into the Itron EquaScan radio system for mobile and fixed
network data collection.
The hMIU
V2 can be refitted at any time to all UltraMaXX/UltraLite with standard housing. The hMIU
RF
bled, installed and integrated into the system of existing EquaScan radio meters in a few simple steps. The hMIU
be programmed and read quickly and accurately via the computer using an Itron inductive head (Ref. No. 8090000006) or
an EquaScan Master
. The parameters are programmed using the EquaScan software.
RF
IMPORTANT NOTICE FOR LITHIUM-BATTERIES
The hMIU
V2 contains non-replaceable lithium metal batteries. Do not charge the batteries, do not expose them to
RF
temperatures above 100°C or to mechanical stress. Transport regulations for lithium batteries must be observed.
The certificates required for transport can be requested from Allmess.
CORRECT DISPOSAL /
INFORMATION ON APPROPRIATE PRODUCT DISPOSAL
The crossed-out garbage container symbol on the hMIU
be disposed of separately from household waste so that it can be handled and disposed of properly. All devices that are
subject to the German Electrical and Electronic Equipment Act (ElektroG) must be recycled properly in accordance with
the German Closed Substance Cycle and Waste Management Act (Kreislaufwirtschafts- und Abfallgesetz). The devices
placed on the market by Allmess GmbH can be returned to Allmess GmbH within the framework of the take-back concept.
Please observe the laws in force in your country regarding the return and proper disposal of electrical devices. The product
is potentially not harmful to human health and the environment, but if it is illegally disposed of in the environment, it will have a
negative impact on the ecosystem. Illegal disposal of the hMIU
responsibility of the user of the hMIU
Further information on our take-back concept and the return form can be found at
https://www.allmess.de/service/verordnungen-gesetze/
The battery symbol on the hMIU
Characteristics
Power supply
Battery life time
Operating temperature
Protection class
Radio specifications
Protocol
Operating mode
Frequency band
V2
RF
• Assembly instructions
RF
V2, if necessary, to delete his private data before disposal.
RF
V2 indicates the end year of the battery life.
RF
3,6 V lithium long-life battery
12 years + 1 year reserve
5°C to 55°C
IP 65
Bidirectional EN 13757-3/-4 wireless M-BUS or unidirectional OMS V
C2 Mode or C1
Tx: 868,95 MHz / Rx: 869,525 MHz
V2 or on the packaging indicates that the old product must
V2 in the environment is punishable by law. It is the personal
RF
V2 can be assem-
RF
V2 can
RF
