Bedienungsanleitung 2. Verbinden Sie direkt das Autoladegerät mit dem USB-Steckplatz des DVR; das Gerät schaltet sich automatisch ein und lädt die Bat- terie. Während des Ladevorgangs leuchtet die Ladeanzeige und erlischt wenn der Vorgang abgeschlossen ist. 3. Um das Gerät über einen USB Anschluss aufzuladen, verbinden Sie ein Ende des USB Datenkabels mit dem Gerät und das andere Ende mit dem PC.
Bedienungsanleitung Tastenfunktionen 1. Drücken Sie die Taste Modus zum Umschalten zwischen Vi- deo/Bild/Wiedergabe, Symbol zeigt Videomodus an, wäh- rend Bildmodus anzeigt. Diese Symbole erscheinen in der linken oberen Ecke des Bildschirms. Aufrufen des Systemeinstellungsmenüs Im Video- oder Bildmodus drücken Sie die Menütaste einmal und danach die Tasten Aufwärts/Abwärts zur Auswahl der System- Einstellungsoptionen: * Schwerkraft Erfassungszustand: Ein/Aus.
Seite 8
Bedienungsanleitung Sie die Taste OK um die Aufnahme zu starten; das Symbol blinkt in der linken oberen Ecke des Bildschirms und ein weißes GPS Symbol erscheint, das anzeigt kein GPS Signal vor- handen; wenn das Symbol grün wird , zeigt dieses an nor- males GPS Signal.
Seite 9
Bedienungsanleitung Wiedergabemodus 1. Dateien suchen Wenn das Gerät das Einschalt-Programm abgeschlossen hat und in den Video-Modus schaltet, drücken Sie die Taste Modus, um in den Wiedergabe-Modus zu gelangen, drücken Sie die Ta- ste AUFWÄRTS / ABWÄRTS um Bilder und Videos zu suchen. Im Wiedergabemodus können Sie die Dateien nur nach Kategorien durchsuchen, wenn der Dateityp Video ist, können Sie nur Videos suchen, wenn Typ Bild, können Sie nur Bilder suchen.
Seite 10
Bedienungsanleitung Klick auf das Symbol zum öffnen und wählen die Datei zur Wiedergabe aus und fügen diese in die Wiedergabeliste AP play track hinzu. Wählen Sie aus der Liste die Datei zur Wiedergabe aus, Klick zur Wiedergabe der gewählten Datei und die kar- te auf der rechten Seite zeigt die Echtzeitposition während der Fahrt an.
Bedienungsanleitung Anschluss an TV 1. Benutzen Sie die HDMI Anschlusslinie um den DVR mit einem TV für Wiedergabe zu verbinden. 2. Benutzen Sie ein TV Kabel um den DVR am TV anzuschlie- ßen für Videoaufnahme, Bildaufnahme und Video oder Bilder zu suchen.
Seite 12
Bedienungsanleitung Batterie 3.7V 400MA Betriebssystem Windows 2000/XP/Vista/Windows 7,MAC OSX 10.3.6 oder höher Die Spezifikationen können ohne Ankündigung geändert werden.
Seite 13
Owner’s manual Appearance and function...
Owner’s manual 1. Bracket clamp 2. Lens ring 3. Lens 4. Speaker 5. USB cover 6. Charge indicator (green) 7. Status indicator (red) 8. Mode key 9. Reset OK key 10. Menu key 11. UP key (MIC on/off) 12. DOWN key (emergency) 13.
Seite 16
Owner’s manual 2. Directly connect the car charger to the USB port of the DVR, then the device will automatically turn on and charge the battery. In charging, the charge indicator will be on; after charge is over, it will be off. 3.
Seite 17
Owner’s manual Switch Working Modes 1. Press the Mode key to switch Video/Image/playback, video mode while as image mode. These icons are screen on the left upper corner of the screen. How to enter system setup option In video or image mode, press the Menu key once and then the Up/Down key to enter the “System Setup”...
Owner’s manual pear, indicating no GPS signals; when such icon turns green , it will indicate GPS signals are normal. Press the video key aga- in to stop videoing, then the icon on the left upper corner will disappear. 2. Set Video Options Press the Menu key to enter the setup of video options.
Seite 19
Owner’s manual 2. Delete and Protect In replay mode, press the menu key to have the options Delete and Protection lock. Press the OK key to enter the options “De- lete the present” and “Delete all”, press the OK to enter and aga- in to confirm.
Seite 20
Owner’s manual Click the icon to open and choose the file to be played, and add the file to the AP play track. Choose the file to be played in the play track, click to play the chosen file, then the map on the right will display your real-time position on during driving.
Owner’s manual Connect to TV 1. Use the HDMI connection line to connect the DVR to a TV for playback. 2. Use a TV cable to connect the DVR to a TV for videoing, sho- oting and browsing pictures and videos. Tip: Without driver installed, the mobile disc may be used when the DVR is switched on.
Seite 22
Owner’s manual Specifications are subject to change without notice.
Seite 26
Instrukcja obsługi 2. Aby naładować baterię, należy podłączyć ładowarkę samocho- dową do portu USB rejestratora. Urządzenie automatycznie się włączy i rozpocznie ładowanie baterii (zaświeci się zielony wskaź- nik ładowania na rejestratorze). Po zakończeniu ładowania wskaź- nik zgaśnie. 3. Urządzenie może być również ładowane z portu USB kompu- tera.
Instrukcja obsługi Zmiana trybu pracy Urządzenie może pracować w 3 trybach: nagrywania video/robie- nia zdjęć/odtwarzania nagrań. Aby zmienić tryb pracy należy naci- snąć przycisk Mode (8). Znajdujące się na ekranie ikony informują o aktualnym trybie pracy: - nagrywanie video, - robienie zdjęć. Ustawienia urządzenia Aby przejść...
Instrukcja obsługi . Migająca biała ikona na ekranie oznacza brak sygna- łu GPS. Po odebraniu sygnału z satelity ikona zmieni kolor na zie- lony . Aby wyłączyć nagrywanie należy nacisnąć przycisk OK (symbole znikną z wyświetlacza). 2. Opcje video Aby przejść do ustawień, należy nacisnąć przycisk Menu (10). Rozdzielczość: FHD(1080P)/HD(720P) Długość...
Seite 29
Instrukcja obsługi 2. Usuwanie i ochrona Z poziomu odtwarzania istnieje możliwość usunięcia i ochrony da- nego pliku. Aby przejść do jednej z tych opcji, należy podświetlić żądany plik i nacisnąć przycisk Menu (10). Ochrona pliku uniemoż- liwia jego przypadkowe usunięcie (po włączeniu ochrony danego pliku, po jego podświetleniu ukaże się...
Seite 30
Instrukcja obsługi Aby wyświetlić listę plików, należy nacisnąć ikonę , wybrać żądany plik a następnie nacisnąć przycisk . Jeżeli podczas nagrywania włączony był moduł GPS, na ekranie dodatkowo wy- świetlona będzie pozycja na mapie.
Instrukcja obsługi Podłączenie do TV Urządzenie może być podłączone do telewizora za pomocą ka- bla HDMI lub TV. Uwaga: Jeżeli urządzenie przestało działać prawidłowo, należy je zresetować naciskając przycisk reset (17). Specyfikacja techniczna Wyświetlacz 2.7″ 960*240 LCD (16:9 HD) Obiektyw 120°A+ Rozmiar video 1080P/720P...
Seite 35
Manual de utilizare 1. Clema suport 2. Inel lentile 3. Lentile 4. Difuzor 5. Carcasa USB 6. Indicator incarcare (verde) 7. Indicator stare (rosu) 8. Tasta Mod 9. Tasta OK 10. Tasta Meniu 11. Tasta SUS (ON/OFF MIC) 12. Tasta JOS (de urgenta) 13.
Seite 36
Manual de utilizare 2. Conectati direct incarcatorul de masina la portul USB al dispozi- tivului DVR, apoi aparatul va porni automat si bateria se va incar- ca. In timpul incarcarii, indicatorul de incarcare va fi aprins, dupa ce incarcarea a luat sfarsit, indicatorul se va fi stinge. 3.
Seite 37
Manual de utilizare Comutarea modurilor de functionare 1. Apasati tasta Mod pentru a comuta modul Video/Imagine/reda- re, pictograma va aparea pe modul video in vreme ce pic- tograma va aparea pe modul imagine. Aceste pictograme apar pe ecran in coltul din stanga sus. Accesarea optiunii de setare sistem Pe modul video sau imagine, apasati tasta meniu o data si apoi tasta sus/jos pentru a accesa optiunea “Setare Sistem”:...
Seite 38
Manual de utilizare din coltul din stanga sus a ecranului va palpai, si picto- grama GPS va aparea, indicand ca nu exista semnal GPS; cand pictograma devine verde , va indica faptul ca semnale- le GPS functioneaza normal. Apasati tasta video inca o data pen- tru a opri filmarea, apoi pictograma din coltul stanga susva disparea.
Seite 39
Manual de utilizare Modul Redare 1. Cautarea de fisiere Cand dispozitivul finalizeaza pornirea programului si intra in mo- dul video, apasati tasta mod pentru a intra in modul de redare, apasati butonul SUS / JOS pentru a parcurge imaginile si clipuri- le video.
Seite 40
Manual de utilizare Accesati pictograma pentru a deschide si a alege fisierul pe care doriti sa-l redati si adaugati fisierul la redarea pieselor AP. Alegeti fisierul dorit pentru redare din lista de redare, apasati ta- pentru a reda fisierul ales, atunci harta din dreapta va afisa pozitia dumneavoastra in timp real in timpul mersului.
Manual de utilizare Conectarea la TV 1. Utilizati conexiunea HDMI pentru a conecta DVR-ul la un televi- zor pentru redare. 2. Folositi un cablu TV pentru a conecta DVR-ul la un televizor pentru vizionare fotografii si navigarea prin imagini si clipuri video. Sfat: Fara driver instalat, discul mobil poate fi utilizat atunci cand DVR-ul este pornit.
Seite 42
Manual de utilizare Specificatiile sunt supuse schimbarilor fara notificare prealabila.
