Specifications
Signal Input
Type
Impedance
Maximum input level
VCF Output
Type
Impedance
Maximum output level
Output noise
Control Inputs
Type
Impedance
CV range
Controls
Signal input level
Cutoff frequency
Resonance
Fixed HPF
Mod input level
Power
Power supply
Current draw
Physical
Dimensions
Rack units
Weight
6 x 3.5 mm jack, AC coupled
50 kΩ, unbalanced
+16 dBu
4 x 3.5 mm jack, AC coupled
1 kΩ, unbalanced
+16 dBu
<-64 dBu, 22 Hz - 22 kHz
6 x 3.5 mm jacks, summed
50 kΩ, unbalanced
0 V to +10 V, 1 V per octave
-∞ to unity gain (0 dB)
20 Hz to 20 kHz
Off to self oscillation
Off, 1 (1 kHz), 2 (2 kHz),
3 (5 kHz)
-∞ to unity gain (0 dB)
Eurorack
40 mA (+12 V),
40 mA (-12 V)
39 x 129 x 81 mm
(1.5 x 5.1 x 3.2")
16 HP
0.19 kg (0.42 lbs)
17
