Connect the lead.
Remove the two screws from the back of the Remote

Controller.

1007332 ISSUE 5
Connect the lead.
Remove the appropriate knock out and fit the back of
the box to the wall.
If the cable is concealed, fit the grommet in the hole to
protect the cable from rubbing.
Secure the cable from the controller in the HPP-i.
Refit the front cover and the top cover.
To check that the installation is correct, set the
temperature on the remote controller to slightly higher
than the pool water. The HPP-i should run to heat
the pool, immediately if the pump synchronisation
is not in use, or at the next sampling period if pump
synchronisation is in use.
Inlet for
exposed cable.
Inlet for
concealed cable.
21
