The device can be mounted in any place by means of double-sided adhesive
tape or wall plugs 5 x (3 x 30) mm.
Mounting by means of wall plugs:
Remove the buttons - to do it press the button on one side, and on the other
side put a screwdriver into a slot and lift up the button (Fig. 1)
Find a place on the wall to mount the transmitter, make two holes corre-
sponding mounting holes from the transmitter's base.
Set wall plugs in the holes.
Fix the base by means of screwing screws into wall plugs.
Place the buttons again.

BATTERY CHANGE

Battery discharge status is signalled by several LED red diode flashes
during transmission time.
Remove the buttons (Fig. 1).
By means of a screwdriver lever up the printedcircuit board releasing the bot-
tom latch (Fig. 2), and remove it from the base.
Remove the battery from the latch (Fig. 3).
Mount a new battery. Watch battery polarisation marked on the latch. Wrong
battery mounting may cause device damage.
Put the removed printed-circuit board back in the base.
Put the buttons back.
CAUTION: While changing the battery, it is suggested to press any of
the buttons for about 5 seconds before putting it into a latch. Next press
transmission button several times to check its operation. If the transmit-
ter does not work properly repeat the battery change procedure.
1
CAUTION! SUBSTITUTING THE BATTERY WITH ANY BATTERY OF INCORRECT TYPE
MAY CAUSE AN EXPLOSIVE HAZARD. DISPOSE OF USED BATTERIES AS STATED IN
2
THE MANUAL.
