Fix the adhesive strips (H) on the back side of
•
the mounting plate (G) in the provided area. You
should be able to read the letters on the back side
(I) (see figure 2).
• Remove the protective film from the adhesive
strips.
• Press the assembled motion detector with the
back side to the wall in the position where it
should subsequently be attached.
5.2

Screw mounting

For mounting the motion detector using screws, please
proceed as follows:
• Choose a site for installation.
Make sure that no electricity or similar lines run in
the wall at this location!
Position the mounting plate (G) on the desired
•
site on the wall. Make sure that the arrow on the
mounting plate is pointing upwards.
Use a pen to mark the positions of bore holes (J)
•
(diagonally opposite) in the mounting plate on
the wall (see figure 3).
• Now drill the bore holes.
