05.2005
Siemens AG 6SE7087-6NP85-0AA0
SIMOVERT MASTERDRIVES
Braking resistor
Signalling relay output X91
DC link bus module
External DC 24 V incoming
supply X9
LED messages
DC 24 V output,
RS485 (USS) X100
Operator control panel X320
Holder for operator control panel
Mains connection X1
Fig. 7-2 Connection overview of 50 kW / 100 kW rectifier units
Operating Instructions
X6
X3
SIEMENS
Run
Failure
Chopper
active
X100
Connecting-up
PE G H
PE3
−
+
7-3
