Connecting-up
NOTE
7-2
Pulse disable ouptput
Fault message output
Braking resistor
capacitor module
DC link bus module X3
external DC 24 V supply
LED messages
DC 24 V output,
RS485 (USS)
Operater control panel
Holder for operator
control panel
Mains connection
Fig. 7-1 Connection overview of 15 kW rectifier unit
Terminal X92 only exists on 6SE7024-1EP85-0AA1.
X92
X91
X6
X9
SIEMENS
Run
Failure
Chopper
active
X100
X100
X320
X1
6SE7087-6NP85-0AA0
Operating Instructions
05.2005
PE3
−
+
