Instruction CF-RU Repeater Unit
Front Cover – fig . 3
Front cover release
Push Button – fig . 4
Push button (for installation/transmission test)

2 . Installation

Note: The Repeater Unit is installed when system enlargement (transmission distance) is
required, or when other system components cannot reach the Master Controller (link test is
unsatisfactory) .
Temporarily connect the Repeater Unit to a 230V power supply outlet no further from the
Master Controller than you can operate both products .
Activate Install mode on Master Controller – fig . 4
•..
Use the menu selection button
flashes
•..
Activate Install mode by pressing OK

VI .UH .N1 .52
to select the Install mode. Install LED
. Install LED
Produced by Danfoss Floor Heating Hydronics 08.2008
goes ON
