Anleitung_STS_85_elec_SPK7:_
GB
Position 1: Small pendulum action
Material: Plastic, wood, aluminium
Please note: For hard materials
Position 2: Medium pendulum action
Material: Wood
Position 3: Large pendulum action
Material: Wood
Please note: For soft materials and sawing along the
grain
The best combination of speed and pendulum action
depends on the material you wish to saw. We
recommend you to make a trial cut on a waste piece
in order to check the ideal settings.
6.5 LED lamp (Fig. 13/Item 16)
The LED lamp (16) can be used in poor lighting
conditions to additionally illuminate the cutting
position. Press the switch (17) to switch on. To switch
off, press the switch (17) again.
6.6 Making cuts
Ensure that the ON/OFF switch (3) is not
depressed. Only then should you connect the
mains plug to a suitable socket.
Do not switch on the jigsaw until you have fitted a
saw blade.
Use only saw blades that are in perfect condition.
Replace blunt, bent or cracked saw blades
immediately.
Place the saw foot flat on the workpiece you wish
to saw. Switch on the jigsaw.
Allow the saw blade to accelerate until it reaches
full speed. Then slowly move the saw blade along
the cutting line. Only exert gentle pressure on the
saw blade as you do so.
When cutting metal, apply a suitable coolant
along the line you wish to cut.
Always clamp small, thin and flexible workpieces
on a sturdy surface.
Important.
Do not carry out plunge-cuts.
6.7 Sawing out sections (Fig. 14)
Important.
Start up the jigsaw only after inserting the saw blade
into the hole.
Drill a 10 mm hole in the section you wish to saw out.
Insert the saw blade into this hole and start to saw out
the required section.
22
27.12.2010
11:15 Uhr
Seite 22
6.8 Making parallel cuts
Mount the parallel stop and adjust as required
(see section 5.3).
Observe the instructions in section 6.6.
Cut as shown in Figure 15.
6.9 Making miter cuts (Fig. 16)
Set the angle on the soleplate (see section 5.4).
Observe the instructions in section 6.6.
Cut as shown in Figure 16.
7. Replacing the power cable
If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
8. Cleaning, maintenance and ordering
of spare parts
Always pull out the mains power plug before starting
any cleaning work.
8.1 Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
We recommend that you clean the device
immediately each time you have finished using it.
Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts of
the equipment. Ensure that no water can seep
into the device.
8.2 Carbon brushes
In case of excessive sparking, have the carbon
brushes checked only by a qualified electrician.
Important! The carbon brushes should not be rep
laced by anyone but a qualified electrician.
8.3 Maintenance
There are no parts inside the equipment which
require additional maintenance.
