Anleitung_STS_85_elec_SPK7:_
5.4 Setting the soleplate for miter cuts (Fig. 7)
Undo the locking screw (18) on the soleplate.
Pull the soleplate (7) slightly forward. The
soleplate can now be swiveled a maximum 45° to
the left and right.
If the soleplate (7) is pushed back to the rear
again it will only function in the locking positions
at 0°, 15°, 30° and 45°, which are marked on the
graduated scale for the soleplate (9). Move the
soleplate into the required position and refasten
the locking screw (18).
However, the soleplate (7) is also easily set to
another angle. To do so, slide the soleplate (7)
forwards, set the desired angle and refasten the
locking screw (18).
5.5 Adapter for dust extraction system (Figure
8/Item 6)
Connect your jigsaw to a vacuum cleaner using
the adaptor for dust extraction (6). This will
provide excellent dust extraction on the
workpiece. The benefits are that you will protect
both the equipment and your own health. Your
work area will also be cleaner and safer.
Dust created when working may be dangerous.
Refer to the section entitled "Safety instructions".
Fit the adapter (6) as shown in Figure 8. The
adapter (6) must audibly engage to ensure that it
is secure in the soleplate (7). The adapter for chip
extraction (6) cannot be used for miter cuts.
Fit the vacuum tube of the vacuum cleaner onto
the adaptor opening (6). Check that the
connections are airtight.
5.6 Holder for saw blades (Fig. 9/Item 4)
There is a holder for saw blades on the jigsaw (4).
This holder can be taken off the machine. To do this,
slide the holder backwards. To secure the holder (4)
place it in the appropriate guides and then slide the
holder forwards.
27.12.2010
11:15 Uhr
Seite 21
6. Operation
6.1 ON/OFF switch (Fig. 10/Item 3)
To switch on:
Press the ON/OFF (3) switch
To switch off:
Release the ON/OFF (3) switch
6.2 Locking button (Fig. 10/Item 2)
You can lock the ON/OFF switch (3) using the locking
button (2) when the equipment is in operation. To lock
it, press the ON/OFF switch (3) and slide the locking
button (2) to the left or right. To switch off the
equipment briefly hold down the ON/OFF switch (3).
6.3 Electric speed selector (Fig. 11/Item 1)
You can pre-select the required speed with the speed
selector. Turn the speed selector in PLUS director to
increase the speed and turn the speed selector in
MINUS direction to reduce the speed. The suitable
stroke speed is dependent on the relevant material
and working conditions.
General rules for cutting speeds for metal cutting
work must be complied with here as well.
You can generally use a higher speed with fine saw
blades whilst coarser saw blades require lower
speeds.
Position 1-2 = low stroke speed (for steel)
Position 3-4 = medium stroke speed (for steel, soft
metal, plastic)
Position 5-6 = high stroke speed (for softwood,
hardwood, soft metal, plastic)
6.4 Setting the pendulum action (Fig. 12/Item 8)
The strength of the pendulum action of the saw
blade (12) can be adjusted using the selector
switch for pendulum action (8).
You can adjust the cutting speed, the cutting
performance and the finish to the workpiece you
wish to saw.
Set the selector switch for pendulum action (8) to one
of the following positions:
Position 0: No pendulum action
Material: Rubber, ceramic, aluminium, steel
Please note: For fine and clean cuts, thin materials
(e.g. sheet steel) and hard materials.
GB
21
