2.6 Technical data

2.6.1

Refrigeration data

Designation
Cooling capacity (L 35 / W 10 / 200l/h) *
Coolant
Thermostat setting
Thermostat setting range
Water quantity *
Water supply temperature
Operating pressure *
Air volume flow
Ambient air temperature
Switch cabinet interior temperature
Duty cycle
Sound pressure level (1m)
Condensate separation
2.6.2

Electrical data

Designation
Rated operating voltage * / **
Rated frequency *
Power consumption *
Rated current*
Max. rated current
UL at 60 Hz *
Starting current +
Upstream fuse T *
Functional range
Temperature monitoring (Alarm)
Switching point via setpoint
2.6.3

Dimensions

Designation
Height x width x depth PWS
Height x width x depth PWI
Installation depth
Weight
Installation position
Unit construction
2.6.4

Other unit data

Designation
Cooling water connection
Anti-corrosion protection
Protection type
* Data on the type plate.
Operating manual PWS and PWI 6152 086100045b © Pfannenberg GmbH
Model PWI/PWS 6152 400V
Model PWI/PWS 6152 400V
50Hz
P
el
77W
A35/W10
0,35A
I
nom max
I
nom max
60Hz UL
I 0,49A
Start max
Model PWI/PWS 6152 400V
Model PWI/PWS 6152 400V
Hose nozzle in accordance with DIN 8542 R1/2'' (13 mm)
Standard: Galvanized, electrostatic powder-coated (200°C)
Variant: Stainless steel cover
When used as intended:
IP 55 against the switch cabinet (EN 60529).
** With a change to the rated operating voltage, adapt the upstream fuse;
see Adapting the upstream fuse
Model PWI/PWS 6152 460V
1500W
Water
+35°C / 95°F
min. 8°C / 46,4°F - max. 50°C / 122°F
200 l / h
10°C (>+1°C bis +35°C)
1 to 10 bar
885m 3 / h
+1°C / 34°F . . . +70°C / 158°F
+1°C / 34°F . . . +50°C / 122°F
100%
≤ 54 db (A)
Condensate drain (pipe
Model PWI/PWS 6152 460V
400V
60Hz
76W
0,35A
0,4A
0,59A
2A gG
DIN IEC 60038
max. 230V AC, 8 (1,5) A cosφ=1 (0,6)
max. 230V DC, 0,25A
+10K
Model PWI/PWS 6152 460V
945,5 x 410 x 142 mm
938 x 410 x 142 mm
60 mm
PWI: 16 kg / PWS: 18,5 kg
Vertical
Standard: Steel sheet
Model PWI/PWS 6152 460V
.
ᴓ
=12mm)
460V
60Hz
75W
0,31A
0,4A
0,59A
Page 8 / 31
