For All Models - Atlas Copco LUM22 HRX 3 Bedienungsanleitung

Fig. 11 Motor casing

For all models

L mm
OFF 2 Nm
2 mm
28
27
26
= Included in
Service Kit
Ref. No. Ordering No.
1 (5 - 38) 4210 3617 82
5 (6, 7) 4210 3624 90
6 0663 9021 00
7 –
10 –
11 0663 2103 37
12 –
13 4210 3616 02
15 (16-19) 4210 3625 80
16 0663 6126 00
17 –
18 –
19 –
20 (21-24) 4210 3626 80 b
21 0663 6124 00
22 –
23 –
24 0335 1100 02
36
39 40
41
(45)
LOCTITE 222
33
32
31
30
29
25
OFF
16 mm
NB Qty Description
1 Motor casing, compl.
1 Cover, compl.
1 O-ring (21.1x1.6)
1 Cover
1 Motor casing
1 O-ring (25x2)
1 Filter
1 Handle
1 Deflector, compl.
1 O-ring (19.1x1.6)
1 Net
1 Silencer
1 Exhaust deflector
1 Adapter, compl.
1 O-ring (17.1x1.6)
1 Adapter (G 1/4")
1 Strainer
1 Circlip (A20x1.2V)
Atlas Copco Tools – No. 9836 1945 01
50
42
38
37
36
35
34
21
20
20 Nm
22
23
24
Ref. No.
25 (26 - 38)
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40 (41, 42)
41
42
a Included in Service Kit – Ordering No. 4081 0196 90
b With 1/4" NPT-thread (for the US and Canada) : 4210 3626 82
45
10
11
12
Ordering No. NB Qty Description
4210 3621 91 1 Valve, compl.
4250 1660 00 1 Push button
4210 3622 00 1 Valve pin
0196 1167 00 1 Stop screw (SK6SS 4x5)
4250 1658 00 1 Reversing knob
– a 1 Spring
– a 1 Retainer pin
4210 3620 00 1 Reversing valve
– a 1 O-ring (3.6x1)
– 1 Valve sleeve
4250 1935 03 1 Washer
– a 1 O-ring (2x1.5)
– a 1 O-ring (14.1x1.6)
– a 1 Pin (2x22)
4210 2010 00 1 Silencer
4210 3628 90 1 Valve seat, compl.
– 1 Valve seat
0663 6127 00 1 O-ring (22.1x1.6)
181 / 165
6 7
5
OFF 20 Nm
13
1
16
17
15
18
19
