5.Installation guide
Step 2 (B1): Installation of step jaws jaws (method 1)
Ladder jaws
Screw 3*6mm
H2.5 hexagonal
plate hand
Key points of operation: The sphere should be flattened by the three claws, and then the support
column Flatten the sphere with the suction cup, and then tighten the screws. Disassemble the
sphere, you can loosen the chuck first, and then move the support back column.
Note:
1. When engraving a curved surface, take the average value of the diameter/circumference of the
actual engraving range of the measured object (the average value of the left, middle and right of
the engraving range position)
2. When tilting and engraving, adjust the appropriate position of engraving by rotating the button
3. Round bottom object engraving
Support column assembly
9
