IP Adress
Subnet mask
Gateway
Username
Password
After successful installation and start of the software, you can scan the system with the
search setting PROFINET-Gerät. The PROmesh B8 is displayed in the search result. You
can then make and save individual entries in the input mask.
! NOTE Make sure that the IP address you selected has not yet been assigned. If required, you
can display IP addresses that have already been assigned using the PROscan® Active V2
license software from Indu-Sol.
When logging in for the first time, you must change the factory-set password. It is your
! WARNING
responsibility to document this password and protect it against unauthorized access
Accessing the Web User
Interface
The device-specific functions of the PROmesh B8 can be configured via an integrated
Web-UI. Open your browser, enter the IP address of the PROmesh B8 configured in the
ServiceTool in your browser bar or use the above configuration data. Alternatively, you
can right-click on the corresponding list entry in the context menu of the ServiceTool
to select „to website". The Web UI now opens in your standard browser.
Further information on the configuration options and troubleshooting can be found at
! NOTE
the following link:
https://sdx.indu-sol.com/s/WnL7ddafkq77cqZ
14
0.0.0.0
0.0.0.0
0.0.0.0
admin
admin
ENGLISH
Interpreting LED Displays
LED label Mode Meaning
VDC1 Green Voltage at terminal sufficient
Off Voltage at terminal insufficient
VDC2 Green Voltage at terminal sufficient
Off Voltage at terminal insufficient
Status Green Active connection to the PROFINET controller
Yellow No active connection to the PROFINET
controller
Error Red Power failure, port error or configured alarm
active
Off No power failure, no port error and no confi-
gured alarm active
Port Status On The port has established a valid network
connection
Flashing The port is in network communication
exchange
Off The port has not established a valid network
connection
