TRILUX SYMBOL LED-Serie Demontageanleitung Seite 6

EN
For your safety
Read all notes and disassembly steps care-
fully.
Explanation of the warning levels
Observe and follow the warnings. Non-obser-
vance of the warnings may lead to injuries or
material damage!
WARNING! Indicates dangers which
can result in serious and/or fatal
injuries.
CAUTION! Indicates dangers which
can result in injuries or health haz-
ards.
NOTICE. Indicates dangers which can
result in material damage or mal-
functions.
TIP. Indicates information containing
advice or a useful note.
Explanation of important symbols and pic-
tograms
Identifies expert personnel trained
and authorised to perform disassem-
bly.
Safety notes
WARNING! Risk of electric shock!
Never work on the luminaire with
voltage applied.
CAUTION! Risk of injury! Install the
luminaire components using protec-
tive gloves.
NOTICE. Avoidance of damage to
electrical components. Take mea-
sures for ESD protection.
TIP. The instructions show the steps
to be taken exemplarily for the type
of luminaire shown. The number of
components may vary.
6 | 30
Disposal of waste electrical and electronic
equipment
Always collect and dispose of old
electrical and electronic equipment
separately at the end of its service
life. In case of doubt, seek informa-
tion about environmentally-compli-
ant waste disposal from your local
district authority or special waste
disposal companies. Current infor-
mation on the energy efficiency class
of the selected product version can
be found in the corresponding data
sheet for the luminaire. Instructions
for replacing or removing the light
source in accordance with Regula-
tion 2019/2020/EU can be found at:
www.trilux.com/EcoDesign
Disassemble LED module and control gear
unit
Pos.
1.
10 Open the cover. (2x)
2.
20 Open the flap by pivoting.
3.
30 Remove the cover.
4.
40 Loosen the screw. (2x)
5.
XX Disconnect the cable from the con-
trol gear unit using an auxiliary tool.
6.
50 Remove the control gear unit.
50 The control gear unit is completely
removed.
7.
60 Loosen the screw. (2x)
8.
70 Remove the cover.
9.
80 Loosen the screw. (4x)
DMA-10096 | 220120 | © trilux.com
SYMBOL LED
