EN Manual
First use
Connect the Alarm Clock with the provided QC3.0 230V power adapter +
Type-C USB cable and press the RESET-button with a paperclip at the back.
Then the light of the screen will display '0000' '1111', '2222', '3333', '4444'
,'5555' ,'6666' ,'7777' ,'8888' ,'9999' in turn, and then show some dots on the
screen. Now you will hear a buzzer ring a sound like "Bliep". It will enter the
time mode, the default time is 12:00, 24-hour with the default date.
Time setting
Long press the TIME button to enter the TIME setting, and then click the
TIME button to select the time display to be adjusted. The adjustable
mode sequence will be YEAR, MONTH, DAY, HOUR, MINUTE, 12/24* hour
switching setting. After selecting the time display (when flashing), turn the
adjustment wheel to adjust year, month, day, hour and minute at the same
time. Press TIME to confirm after each setting for the working status of time
display. The system will automatically save your setting and return to time
display if no further action within 10 seconds.
*After setting the time display mode as 12-hour, the PM display will be
replaced by the light at the top left.
Alarm mode setting
Long press the ALARM button to enter the ALARM setting (the time position
and bell symbol will flash at the same time), the alarm is a total of 1 group,
and the position where the alarm is flashing is the one to be adjusted.
After selecting the correct time alarm (when flashing), turn the adjustment
wheel to adjust the alarm hour + or – and press ALARM to confirm and
re-enter the alarm sub setting mode. After all is completed press ENTER
again to return to the normal display time interface. TIP: When the alarm
is turned on, the alarm symbol will be on constantly. When alarm time is
achieved, alarm will sound and the alarm symbol will flash till the alarm is
switched OFF again.
Alarm clock / snooze
Toggle/Slide switch control alarm setting to be ON or OFF. The alarm switch
is controlled by the toggle/slide switch, turn on the alarm, and the alarm
symbol is always on. The alarm is heard and the alarm symbol flashes at the
same time. When the alarm is sounded and till press any other key to enter
the snooze manually. The number of snoozes is 5 times, and each snooze
is 9 min, press any key to turn off the alarm in the snooze state, and it will
activate automatically the next day in the alarm again.
Charging your QI-compatible mobile phone
Simply place your QI -Compatible device on top middle section (at wireless
icon) of the CLOCK, it will start charging automatically and the phone
charging indicator will light up.
Display mode
Press 1x TIME to switch the display mode: DP-2 fixed display time
temperature, DP-1 time + temperature display for 10 seconds and switch
month and day displayed for 2.5 seconds and switch display temperature
for 2.5 seconds again. TIP: C/F temperature conversion: switching by
pressing 1x 'ALARM' in normal clock state. The temperature ranges from
-20°C. to 50°C. or -4°C. to 122°C.
Brightness adjustment
Dial the turn knob adjustment wheel in normal mode to adjust the
brightness of 7 levels. Brightness has a memory function, during the day
time (7:00-17:59) adjust the brightness to remember the brightness of the
daytime period, and at night (18:00-6:59) adjust the brightness to remember
the brightness of the night time period. If the brightness is not set manually,
18:00-6:59 (default L1 is the darkest), 7:00-17:59 (default L7 is the brightest)
automatically.
Sound control switch setting
Press 1x ENTER to switch the voice switch, ONSD turns ON the sound
control display for 13 seconds and to turn off the screen after that. From
now on if any sound or voice is greater than 75dB it will wake-up the display
(like by tapping the top or side of the clock during night). If switch to --SD it
turns OFF the sound control and the display is always ON again.
Alarm tone setting
Long press ENTER to enter the sound type adjustment. The display will
show U1-U5 and at the same time a "bliep-bliep" is sounded. Then toggle
the adjustment wheel knob to adjust the sound volume as desired.
Reset function
When some of the functions is abnormal or the display or functions are
abnormal (such as nothing displayed in the screen when the power is
plugged in or even when the battery is installed), press the RESET button on
the back of the product to re-activate all.
