2.1 Brief Introduction

Plasma 40D / Plasma 60 / Plasma 70PD / Plasma100PD plasma cutting machines adopts
the latest pulse width modulation (PWM) technology and insulated gate bipolar transistor (IGBT)
power module, which can change work frequency to medium frequency so as to replace the
traditional hulking work frequency transformer with the cabinet medium frequency transformer.
Thus, its characterized with portable, small size, light weight, low consumption and etc.
Plasma 40D / Plasma 60 / Plasma 70PD / Plasma100PD plasma cutting machines
Characteristics:
◆IGBT technology.
◆With EMI filter to minimize the pollution of the electrified net.
±
◆High mains voltage tolerance
15%to maintain stable work.
◆MCU control system, responds immediately to any changes.
◆Excellent cutting capability.
◆Pilot arc controller, can cut grid workpiece.
◆Intelligent protection: over-current, over-heat, when the mentioned problems occoured,
the alarm lamp on the front panel will be on and the output current will be cut off. It can
self-protect and prolong the using life.

2.2 Specifications

Description Plasma 40D
6kg
Weight
Power source dimensions 375x152x291
Fan cooled
Cooling
Welder type Inverter power source
European standards
EN 60974-1 / IEC 60974-1
1 x 230 Volt ±15%
Mains voltage
Grid frequency
50/60Hz
20-40 A
Cutting rurrent range
Effective input current 15.6A
Maximum input current 28.5A
Generator requirement
10KVA
40A@ 30%96V
Duty cycle, 40°C, 10 min
25A@ 100%90V
Open circuit voltage
330V DC
Schutzgrad IP23
Protection class
H
Quality cutting thickness (500mm/min)
8mm
Maximum cutting capacity 12mm
31
Plasma 60D
6.5kg
425x152x291
Fan cooled
Inverter power source
EN 60974-1 / IEC 60974-1
3 x 400 Volt ±15%
50/60Hz
20-60A
8.8 A
19.7A
15KVA
60A@ 60%104V
46A@ 100%98V
330V DC
IP23
H
15mm
20mm
PLASMA CUTTING SERIES EQUIPMENT
Description Plasma 70PD
Weight 7kg
Power source dimensions 425x152x291
Fan cooled
Cooling
Welder type Inverter power source
European standards
EN 60974-1 / IEC 60974-1
3 x 400 Volt ±15%
Mains voltage
Grid frequency
50/60Hz
20-70 A
Cutting rurrent range
Effective input current 10.1A
Maximum input current 22.6A
Generator requirement 15KVA
70A@ 60%108V
Duty cycle, 40°C, 10 min
54A@ 100%102V
Open circuit voltage
330V DC
Schutzgrad IP23
Protection class
H
Quality cutting thickness (500mm/min)
15mm
Maximum cutting capacity
20mm
NOTE
Note 1: The Effective Input Current should be used for the determination of cable size & supply
requirements.
Note 2: Generator Requirements at the Maximum Output Duty Cycle.
Note 3: Motor start fuses or thermal circuit breakers are recommended for this application. Check local
requirements for your situation in this regard.
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all
capacities, measurements, dimensions and weights quoted are approximate only. Achievable capacities
and ratings in use and operation will depend upon correct installation, use, applications, maintenance
and service.
Summary
Plasma 100PD
14kg
594x225x348
Fan cooled
Inverter power source
EN 60974-1 / IEC 60974-1
3 x 400 Volt ±15%
50/60Hz
20-100A
17 A
21.9A
15KVA
100A@ 60%120V
77.5A@ 100%111V
330V DC
IP23
H
30mm
50mm
