VIBIA Class 2820 Montageanleitung Seite 11

Step 4/5
Electrical Connection
4.4B
4.5B
Max. 9 mts.
of cable
- Electric cable (not supplied)
- Cable eléctrico (no suministrados)
- Stromkabel (nicht im Lieferumfang)
- Cavo elettrico (non incluse)
- Câble électrique (non fournies)
+
RED
-
BLACK
B I
C A S A M
Max. 9 mts. of cable
Ø Min. 5 mm
Ø Max. 10 mm
+
-
CLOSED OPENED
+ -
11/14
