EN
2.- INSTALLATION INSTRUCTIONS
- Open the package and check that it is the correct model and it is in good condition.
- To obtain optimum performances it is necessary to
maintain a minimum clearance of 15 cm between the
radiator and any inflammable material as furniture,
curtains etc.
- The rest of clearances required to maintain are
indicated on the following figure:
Position and fix the brackets at the
correct distance from the floor. It is
possible to use the radiator as measuring
unit by positioning it on two polyester
package elements and placing two
supports above as indicated on the
- The studs and screws to attach the
supports are in the accessories bag.
- Hang the unit on the hooks of the
brackets.
- By turning the screws, the metallic
square will go downwards, retaining
the heater. Repeat this on the other
bracket.
Closest
object
to the
left end
Minimu
m
15cm
Minimum 10cm
15
Shelf
Minimum
Minimum 25cm
Control panel side
Mark the fixing points on
the wall using a pencil
through the two fixing
holes in the square brackets
and perform corresponding
bores.
Closest
object
to the
right
