Assembly
Attention! Before the assembly, make sure that the device is not connected to the mains!
1.
1.
Cover with frame
2.
Front grille
3.
Fastening clamp with screw
4.
Lock nut for the wing
5.
Wing
6.
Lock nut for the grille
7.
Rear grille
8.
Motor shaft
9.
Button for swivel function
Handle
10.
11.
Motor housing
Upper stand
12.
12.1
Lower stand
13.
LED display with control buttons
14.
Base plate
15.
Screws
Remote control
16.
12
2.
3.
4.
10.
5.
6.
7.
14.
15.
11.
12.
8.
12.1
16.
9.
