- Place the front part of the radiator level with the top hinge
- Fix the bottom hinge with the nuts provided, using a spirit level to adjust it
- Fix the top hinge with the nuts provided
- Connect the two parts to the plumbing, using the hoses provided
- Check the closure of the radiator using the magnetic fastening.
- Adjust the travel of the magnetic screw.
- Connect the wire for the control panel from the control unit to the panel itself, using
the specific connector.
- For models with LED, connect the button to the LED transformer, using the dedicated
connector.
Adjust the travel of the magnetic screw, in case of lack of tightening.
To adjust the flatness of the radiator/distance
from wall to closed radiator, it is necessary to:
- Loosen nuts 1 and 2
- Tighten or loosen the magnetic screw 3
- Tighten the nuts 1 and 2 after the
correct position has been identified
- Repeat the operation for the remaining
3 magnetic counter-plates
