Setting the light function
For the initial start-up, the battery must be sufficiently charged via direct light
irradiation.
The path and garden light has an easy-to-use 1-button function with 3 levels.
This is located under the lamp head, below the motion detector sensor. To
switch the light on and off, the button must be pressed for a few seconds at a
time.
Level 1:
At dusk, the light automatically switches on with 20 lumens to illuminate a sec-
tion of path or a special spot in the property area.
Level 2:
Switches on the motion sensor. When movement occurs, the lamp here lights
up for approx. 25 seconds with 85 lumens. Afterwards, the lamp continues to
shine with 20 lumens.
Level 3:
Switches on the motion detector. If movement occurs, the lamp lights up here
for approx. 25 seconds with 220 lumens. Then the lamp switches off until the
next motion detection.
1
2
10
Click
20
Lumen
Click
20 Lumen
85 Lumen
20 Lumen
4
Click
Off
3
Click
Off
220 Lumen
Off
